41×41 Square-Edge Rib-Reinforced Galvanized C Purlin with Inner Toothed Structure for Construction

41×41 Square-Edge Rib-Reinforced Galvanized C Purlin with Inner Toothed Structure for Construction

Model Number:	Galvanized square angle 275g C-shaped steel
MOQ:	1000 pieces
Price:	$ 0.9-2.4
Payment Terms:	T/T,PayPal,Xtransfer
Supply Ability:	50000 pieces per day

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Product Name:

Corner 41ｘ41C Purlin

Processing Performance:

Cutting, Decoiling, Punching, Welding, Bending

Usage:

Construction, Electromechanical, Machinery

Length:

1m-12m Or Customer's Requirments

Thickness:

1.5mm / 2.0mm / 2.5mm

Surface Treatment:

Galvanized Coated/Powder Coating

Service:

Custom Metal Fabrication Service

Suitable For:

Lightweight Supports, Photovoltaic Supports, Keels, Roof Trusses, Equipment Frames, Guardrails, Bridge Racks, Etc

Application:

Building Operations

Feature:

Corrosion Resistant, High Strength, Easy Installation, Modular Design

Color:

Silver Zinc

Packaging Details:

Wooden frame or cardboard box packaging, customizable

Highlight:

lightweight galvanized C channel

rib-reinforced serrated C purlin

inner toothed C strut channel

Product Description

41×41 Square-Edge Rib-Reinforced Serrated C Purlin | Lightweight Galvanized C Channel with Inner Toothed (Flowered) Structure for Civil Construction & Home Improvement

Product Description:

This 41×41 square-edge rib-reinforced serrated C purlin (commonly known as "flowered C channel" in the industry for its inner toothed structure) is an upgraded cold-formed steel profile optimized for civil construction and home improvement applications. Manufactured from high-strength thin-gauge steel strip via precision cold forming, it integrates two core upgrades: built-in corner reinforcing ribs and inner serrated flowered teeth.

Compared with ordinary round-corner C channels, the square-edge ribbed design greatly improves sectional rigidity and deformation resistance. The inner serrated "flowered" teeth enhance bolt clamping friction, effectively prevent fastener slipping and improve overall shear resistance of the support system.

It balances sufficient load-bearing capacity with reduced self-weight, allowing single-person handling and installation without heavy lifting equipment. The galvanized anti-rust finish delivers reliable corrosion resistance, suitable for humid indoor environments such as kitchens and bathrooms. The standardized 41×41 profile is fully compatible with mainstream strut channel accessories, enabling fast modular assembly even for non-professional installers, which effectively lowers construction difficulty and shortens project cycles.

Attribute Table:

Attribute	Details
Product Name	41×41 Square-Edge Rib-Reinforced Serrated (Flowered) C Purlin
Core Structure	Square corner + built-in reinforcing ribs + inner serrated flowered teeth
Material	Q235 Carbon Steel; 304/316 Stainless Steel optional
Surface Treatment	Hot-dip Galvanized (HDG) / Electro Galvanized / Pre-Galvanized
Color	Silver zinc finish / stainless steel natural finish
Standard Size	41×41mm (custom sizes available)
Wall Thickness	1.5mm / 2.0mm / 2.5mm (customizable)
Length	1m / 2m / 3m / 6m (custom cut lengths available)
Hole Type	Solid web / slotted holes / custom drilled holes
Load Capacity	Light to Medium Duty (upgraded by corner reinforcement)
Key Features	Corrosion resistant, high rigidity, anti-slip serrated teeth, easy installation, modular design
Application	Pipe hangers, HVAC, fire protection, cable trays, MEP support systems, light steel structures, home renovation
Certification	ISO9001, RoHS compliant
Custom Service	OEM & ODM available (custom size, thickness, hole pattern, finish)
Packaging	Bundled + wooden pallet / as per customer requirements

Features:

Upgraded square-edge ribbed structure

Built-in corner reinforcement ribs enhance overall rigidity and deformation resistance, delivering higher load capacity than ordinary round-corner C-purlins at the same weight level.
Serrated "flowered" inner teeth

The inner toothed structure increases bolt clamping friction, effectively prevents fastener slipping and improves shear resistance, making the whole support system more stable and reliable.
Lightweight & labor-saving

Cold-formed thin-gauge steel maintains low dead weight; single-person handling and on-site assembly without heavy lifting equipment.
Reliable corrosion protection

Galvanized surface finish provides long-term rust resistance, suitable for humid indoor and outdoor civil construction environments.
Strong universal compatibility

Standard 41×41 size fits most common support system accessories for quick modular assembly.
Cost-effective for small projects

Ideal for water supply pipelines, heating pipes, ventilation supports, small steel structures and shelving projects in civil construction and home improvement.

41×41 Square-Edge Rib-Reinforced Galvanized C Purlin with Inner Toothed Structure for Construction

FAQ:

Q: Are you a manufacturing factory or a trading company?

A: We are a professional manufacturing factory specializing in cold-formed steel profiles. You are welcome to visit our workshop at any time. Our facility is equipped with a full set of advanced cold-forming and steel fabrication equipment, ensuring stable product quality and competitive factory-direct prices.

Q: What is your delivery time?

A: Our sales team will confirm the exact lead time based on your order details. For bulk orders, please coordinate with our production department in advance. Normally production is completed within 30 days after deposit receipt, and partial shipment is acceptable for large projects.

Q: Can you offer design service?

A: Yes. Our experienced engineering team can provide customized solutions according to your project requirements. We can supply structural drawings, processing details and installation blueprints for your confirmation at different project stages.

Q: What are your payment terms?

A: 30% deposit in advance, 70% balance settled before shipment.

Q: How do you control product quality?

A: a) Design control: Identify potential risks in advance and deliver reliable structural solutions;

b) Raw material control: Only certified steel materials are adopted for production;

c) Production control: Precision cold-forming technology, skilled operators and strict multi-stage quality inspection.
